BERYL (PRO TOURING)

OVERVIEW

With a pixel pitch ranging from P3.91 to P4.81 mm specially designed for outdoor rental installations. The BERYL is made for rental but can also be used for fixed installations. A user friendly cabinet allowing curved angles, an easy maintenance and a fast installation process.

FEATURES

CURVED ANGLES

CORNER PROTECTION

POWER SUPPLY - PLUG IN PLACE SYSTEM

5 ANGLE ROTATIVE SYSTEM

  • RENTAL LED DISPLAY

  • OUTDOOR (IP65)

  • P3.91 - P4.81

  • 4500 - 5000 NITS @5VOLTS

  • 500 x 500 x 86 mm

  • BACK MAINTENANCE

  • CORNER PROTECTION

  • ALUMINUM ANODISED

  • 9.1 - 16.5 KG/CABINET

OUTSTANDING IMAGE QUALITY

The BERYL was designed to achieve outstanding image quality. Black face SMD provides Broadcast-ready contrast, with a pixel pitch ranging from P2.98 to P4.81, It's one of the easiest and fastest cabinet to maneuver and install.

INSTALLATION

The BERYL has been designed to be user friendly, carrying 9.1kg per cabinets and its tool-less locking system, the BERYL can be easily installed by one Technician. The BERYL innovative sidelock enables concave & convex installation using our 5 angles rotative system. Hanging Bars and Stacking system option is available

RENTAL OUTDOOR

The BERYL is our ultimate solution for outdoor rental installations. With a brand new technology enabling the transportation and installation of an ULTRA HD LED screen with no setbacks or broken led.



BROCHURE

BERYL CLOSE-UP
